CCTV survey: $300–$750
Stands alone and is credited against the works by most operators. Without it nobody can price a liner honestly.
CCTV Surveyed, Then Relined
Pipe Relining
Specialists In
Haberfield
We camera the line first, show you what is actually wrong, and then tell you whether relining is the right answer. Often it is. Where the pipe has collapsed or lost its fall, it is not, and we will say so rather than sell you a liner that disappoints.
- Licence 368473C, fully insured
- CCTV survey before any quote
- Nothing dug up, nothing reinstated
Why No-Dig Suits The Drains In Haberfield
A resin-saturated liner is drawn into the existing pipe through an access point, inflated so it presses against the wall, and cured until it hardens. What you are left with is a continuous pipe inside the old one, with no joints along its length and a slightly smaller bore than the original.
Nothing is excavated, and the cured surface is smoother than the clay or concrete it lines, so flow is typically maintained or improved despite the small loss of diameter. On a property where a driveway, mature garden or paving sits over the line, that is the whole argument.
Conservation areas and what is actually restricted
A listing does not stop you repairing a drain. What it restricts is change that is visible or that disturbs significant fabric, which is precisely what a trenchless repair avoids.
In practice that makes relining the path of least resistance on a listed or conservation-area property: nothing is removed, nothing changes above ground, and there is no reinstatement to get approved.
Relining a trading premises without closing it
Kitchens along the Ramsay Street strip send fats and food waste into drains that build up and block without regular clearing.
For a shop, café or clinic the real cost of a drainage repair is rarely the invoice. It is the days the doors do not open, and an excavation through a floor or a car park is measured in days.
A liner is installed from an existing access point and cures in hours, which is why commercial work is so often scheduled overnight or across a single closed day. The trading interruption is usually the deciding factor, not the price per metre.
Long runs and where the access points sit
Properties on a slope often have long drainage runs, sometimes crossing the whole block to reach the main. The practical questions are where the inspection openings are and whether the liner can be drawn through in one length or needs a second access.
That is worth establishing before quoting. A single long run costs less per metre than the same distance broken into stages, and the difference is decided by access, not by the pipe.
Groundwater going the wrong way
An open joint leaks in both directions. On a low-lying block that means stormwater and groundwater entering the sewer through cracks, which is called infiltration, and it quietly overloads a line that would otherwise cope.
Large established gardens shed leaves and silt that wash into gullies and stormwater drains, clogging them over time.
It shows up as a system that backs up in wet weather and behaves perfectly in dry. If that is the pattern, sealing the run is the fix, and no amount of clearing will reproduce the result.
Old is not the same as beyond saving
People are often surprised that a drain laid before the war is a relining candidate rather than a replacement. Age alone does not decide it. A clay line with a sound barrel and tired joints is close to the best case for a liner.
The cases that genuinely need excavation are different: a collapsed section, a run that has lost its fall, or a pipe crushed out of round. A camera separates those in an hour, and the answer changes the cost by a multiple.
Grease lines, and what relining does and does not solve
A food premises line narrows with hardened fat long before it fails structurally. Relining a greased line without addressing the grease simply gives you a smooth new surface to coat, and the interval to the next problem barely changes.
The right sequence is jet it clean, camera it properly, and then decide. If the barrel is sound the answer may be a service schedule rather than a liner. Where the camera shows cracks or open joints under the build-up, relining is worth doing and the smoother bore genuinely slows re-accumulation.
Selling, buying, or having the line queried
A relined sewer is a genuine asset at sale, and a documented one is worth more than an undocumented one. Keep the certificate, the invoice and both camera runs together with the property file.
If you are buying into an older property in Haberfield, a pre-purchase camera survey of the sewer is one of the cheapest pieces of due diligence available and one of the least often done.
What it costs in Haberfield
Relining, $500–$900 per metre
The usual Sydney range for domestic sewer. Access and junction reinstatement are normally quoted separately.
Patch repair, $1,500–$4,000
One defect in an otherwise sound run. The proportionate answer on stable ground, and the wrong answer on a line with twenty tired joints.
Full domestic run, $6,000–$15,000
Where the camera shows the same failure repeating along the length. Ends the problem rather than relocating it.
Excavation, from $2,500 plus reinstatement
The honest comparison. Cheaper on an open lawn, rarely cheaper under a driveway, paving or a building.
Indicative Sydney ranges for 2026. Your job is quoted in writing after the camera survey. Figures here are indicative of the 2026 Sydney market rather than a quote from us, you get your own number as a fixed price before any work starts.
How A Relining Job Runs
Step 01
Step 01
Camera The Line
A CCTV survey establishes the material, the diameter, where the defects are and how far they sit from the access. You see the footage, and it is what the quote is built from.
Step 02
Agree The Method
Patch or full length, and occasionally excavation instead. We will tell you when digging is the better answer even though it is the bigger quote.
Step 03
Clean, Line And Cure
The run is jetted so the liner bonds to pipe rather than debris, the liner is installed through the existing access, and it cures in place. Most domestic jobs are a single day.
Step 04
Reinstate And Re-Camera
Every branch the liner passed is reopened from inside, then the run is cameraed again so you can see it is continuous and the junctions are clear.
Rather Talk It Through First?
Send it through and we will come back with what it is likely to be, what the survey costs, and whether relining is even the right conversation.
Most domestic relining is a single day on site: set up at an existing access point, jet and camera the line clean so the liner bonds to pipe rather than debris, install, cure, then reinstate the junctions and camera it again. Water is off for part of the day. Larger or commercial runs are staged, and are often scheduled overnight or across one closed day so the premises can trade.
It depends on the policy and, more importantly, on the cause. Gradual deterioration and tree root intrusion are commonly excluded, while sudden accidental damage is often covered. That distinction is settled on evidence, which is why dated camera footage showing the defect and its position is worth keeping even if you never claim. It cannot be reconstructed after the repair.
No. A liner takes the shape of the pipe it cures inside, so it cannot correct a run that has sagged into a belly or lost its fall, and it has nothing to line against where a section has collapsed. Badly deformed or crushed pipe needs replacing. What relines well is the common case: a sound barrel with cracked or open joints, which is most older clay drainage.
Because it is rarely on one generation of drainage. Original clay, a 1970s junction and a modern PVC section on the same line is a normal finding, and the transitions between them are where most faults sit. A slower survey is what prevents relining a run that actually needed one junction rebuilt.
In a strip of tenancies the drainage is often shared, so the fault is frequently not under the premises reporting it. Settle it before the quote rather than after. Camera footage with distances marked from a known access point is what makes the conversation with a landlord or neighbouring tenant short, because it shows exactly where the defect sits.
Only if the cause is a defect rather than the gradient. On a steep run, waste can outrun the water carrying it and settle at the first flat section, producing a blockage at the same point regardless of the household. A liner seals the pipe but keeps its shape, so if the profile is wrong the pooling continues. The camera run distinguishes the two.
Yes, along the relined length. Roots do not attack sound pipe, they find a way in through an open joint or crack, and a liner is continuous with no joints for them to exploit. Cutting roots out clears the pipe but leaves the entry point exactly as it was, which is why jetted lines tend to reblock on a predictable interval.
Talk To A Relining Specialist In Haberfield
Ring us or leave your details. You will get a time for the inspection, not a price invented over the phone.
